TNAttachments Auger Drive for Skid Steer Loader

2.5 - 3.8T (5,500lbs - 8,400lbs)

Features

Compact high-torque Digga manufactured gearbox
Digga designed Eaton motor with integrated PRV eliminates the need for bulky valve blocks and reduces potential leak points
2 Piece shaft design ensures maximum side load ratings without increasing load on bearings
5 Year gear box and 3 year motor warranty / lifetime shaft pull-out warranty
Over 30 years design and manufacturing experience
Easily converted to a Screw Anchor Drive with the addition of our patented 'Anti Kickback Valve' (ECV)

5 Year

Gearbox Warranty

3 Year

Motor Warranty

Single Speed

Model3DSS4DSS4DDS
Torque FT-LBS @ 3000 PSI2,8293,2753,583
Max Torque FT-LBS @ 3500 PSI3,3003,8214,180
Recommended Flow (GPM)10-3010-3010-36
Motor TypeEATONEATONEATON
Max Pressure - DO NOT EXCEED3500 PSI @ 16 GPM3500 PSI @ 16 GPM3500 PSI @ 27 GPM
Max Flow - DO NOT EXCEED30 GPM @ 1800 PSI30 GPM @ 1800 PSI42 GPM @ 3100 PSI
Max Horse Power333355
Pressure Relief Valve (PRV)N/AN/AIncluded
Standard Output Shaft2" Hex2" Hex2" Hex
Halo (Auger Alignment)OptionalOptionalOptional
Recommended AugerA4 / RC4A4 / RC4A4 / RC4
Max Drilling Diameter Clay/Shale *24"24"24"
Max Drilling Diameter Earth *30"30"40"
Weight (lbs)123125180
Overall Length (in)25.9"25.9"29"
Diameter (in)9.4"9.4"9.4"

Output Speed & Torque

Output speed and torque specifications are THEORETICAL. Speed and torque output are dependant on the overall system efficiencies associated with the prime movers hydraulic system. This document should be used for information and comparative purposes only. When determining criteria & application-specific information is required, please contact Digga.

* Max/min drilling diameter (DIA) dependant on ground conditions. Guide is a recommendation only.

3DSS
Output SpeedOutput Torque
GPM RPMPSI FT-LBS
10 331,500 1,414
12 391,700 1,603
14 461,900 1,792
16 522,100 1,980
18 592,300 2,169
20 652,500 2,357
22 722,700 2,546
24 782,900 2,735
26 853,100 2,923
28 913,300 3,112
30 983,500 3,300

4DSS
Output SpeedOutput Torque
GPM RPMPSI FT-LBS
10 281,500 1,638
12 341,700 1,856
14 391,900 2,074
16 452,100 2,293
18 512,300 2,511
20 562,500 2,730
22 622,700 2,948
24 672,900 3,166
26 733,100 3,385
28 793,300 3,603
30 843,500 3,821

4DDS
Output SpeedOutput Torque
GPM RPMPSI FT-LBS
8 221,500 1,791
13 321,700 2,030
17 431,900 2,269
21 542,100 2,508
25 652,300 2,747
29 752,500 2,986
34 862,700 3,225
38 972,900 3,463
42 1083,100 3,702
3,300 3,941
3,500 4,180

Augers to suit 3DSS, 4DSS, & 4DDS

Features

TRU-CUT - a 12" auger cuts a 12" hole, no more oversized holes!
Over 30 years of auger design and manufacture has resulted in an extremely efficient cutting head design and optimum flight pitches to provide maximum soil removal in all ground conditions
Made in the USA
Easy knock in and out teeth requires no special tools

General Purpose Auger

Dig holes in earth conditions and clay
Available Size: 6" to 60"
60" Overall length
Earth and Tungsten teeth available

Combination Rock & Earth Auger

Dig holes in earth conditions, clay, asphalt, concrete, and fracturable rock
All purpose cutting heads - no more interchanging cutting heads & using multiple augers
Available Size: 6" to 60"
60" Overall length
